Aluminum Panel Photo Gallery

Now only $256 for a 4’x8′ sheet.

Size Sqft Price
4’x8′ 32sqft $256/sheet
4’x10′ 40sqft $320/sheet
over 4’x10′ any size Ask for price

Custom Sizes Available

If you have a special custom, architecturally specified, or otherwise unique requirement for your project, don’t hesitate to ask. We are experts in the unexpected, and seek to exceed your every desire. Visit our pricing page for more information and to submit your price quote request.



singcoreadmin No Comments

Stock Panels

Note: This is an archived page and is no longer available. For current information visit us online at: singcore.com

4 ft. x 8 ft. Standard Sandwich Panels

stack-of-structural-marine-plywood-torsion-box-foam-composite-panels-yacht-buildersEven though Sing Sandwich panels are available in any size, any thickness and host any exterior surface, the following standard panels are regularly stocked sandwich panels and are our most popular honeycomb panels. These advanced composites are the most widely used for a wide variety of applications. Click here to see some of the vast uses of our standard Sing Sandwich panels.

Best use = Substrate
Sing Sandwich panels are best used as substrate for:

Advantages

  • Solid as a rock
  • plywood can be bonded w/regular white glue
  • cold or vacuum press

How to Build

  • For more information on how to build using Sing Sandwich panels, Click Here
Product Total Thickness Grid Size Skin Thickness
Plywood 3/4 inch 2 in. x 2 in. 1/8 inch
Plywood 3/4 inch 3 in. x 3 in. 1/8 inch
Plywood 1 inch 2 in. x 2 in. 1/4 inch
Plywood 1 inch 3 in. x 3 in. 1/4 inch
Plywood 1.56 inch 2 in. x 2 in. 3/8 inch
Plywood 1.56 inch 3 in. x 3 in. 3/8 inch
Aluminum 3/4 inch 2 in. x 2 in. .032
Aluminum 3/4 inch 3 in. x 3 in. .032
Aluminum 1 inch 2 in. x 2 in. .040
Aluminum 1 inch 3 in. x 3 in. .040
Aluminum 1.56 inch 2 in. x 2 in. .063
Aluminum 1.56 inch 3 in. x 3 in. .063



foam-panel-guaranteed-true-flat-lightweight-strongCompare Sing Sandwich panels to other sandwich panel core materials.

Sing Core Foam Choice: Our stock sandwich panels feature extruded polystyrene as rigid insulation but may be upgraded to polystyrene to meet your specifications at an additional charge.

Sing Edge Option: Sing Sandwich panels have no solid edge. In the event that you require wood edges (or edges and/or implants of plastic or aluminum) Sing Panels would be better suited for your use.

Sing Sandwich vs. Sing Panel: Our regularly stocked and most in-demand honeycomb panels are our plywood panels and aluminum metal panels which are lightweight and stronger than steel pound for pound.

How to BuyMetal Composite Sing Core panels are true straight, light and strong.

To order Sing Stock Panels submit an order form either by email, info@singhome.com, or print and fax it to: 360.495.4585. We’ll provide a quote within one business day. If you have questions, please contact us.

Easy Ordering

All we need to know is the length, width, thickness and what you desire on the exterior, and your custom specialty panels are made to order. Getting a quote for your specialty product, is easy, thanks to our simple online order system.

Bulk Discounts

If you’re looking for a bargain price, remember, the more you order, the less expensive your total order will be per piece. Quantity and wholesale inquiries are encouraged. Feel free to contact us for more information. Click here for Closeout specials.

Fast turnaround: In you’re in a rush, only Sing Core can be custom made within 24 hours and is proudly manufactured for you in the USA.

Fast delivery: Any thickness and almost any length, less than 5 ft wide, can be made with in 48 hours if it is rush order.

SINGCORE Stock Panels are easy to order. You may choose from our stock panels or order custom sized panels. Our price is based on the length, width, thickness, and quantity. Submit a Work Order by fax or email, and we will give you a quote within one business day. If you have a tight budget, give us a call, we might have an alternative solution tailored to your needs.

singcoreadmin No Comments

Sing Core Panels

Applications/Uses

Doors
Museum & Trade Show Panels
Sing Metal Composite Panels
Sing Post & Beams
Sing Ceilings
Furniture
Flooring
Sing Tiny house

torsion box, sandwich panel, honeycomb panel, lightweight panel

Peter Sing- inventor and president of Sing Core- spent forty years of his life to create this new sandwich honeycomb panel technology and with hard work and great perseverance, he has succeeded in his goal. His next step for his company, is to spread the word out to everyone. Peter Sing believes that people are crazy for settling with heavy, non-versatile, and expensive plywood/particle board when they can use Sing Core’s lightweight, affordable, and reliable honeycomb panels.

Imagine being able to use a lightweight, strong, wooden honeycomb panel that allows you to create anything from basic furniture or large sliding door to an entire house that you live in. But Sing Core is cheaper and friendlier to the environment. Sounds too good to be true, but it’s not, because Sing Core Honeycomb Panels give you that advantage. This new and innovative style of honeycomb panel is so much more than lightweight, strong, and durable; it is long lasting, reliable, simple, and affordable.

Why use thick plywood- that can be difficult to construct with- when you can use the versatile Sing Core honeycomb panels. Through Sing Core, you will have the components to be able to build thousands of Sing Core products, with that eco friendly touch.



Pictured to the right is a 1 ton truck on a piece of 1/4″ inch thick Hardy Plank wrapped around our Honeycomb core. it does not crack under the pressure of a 1 ton truck. This is the future economical, concrete home structure. The picture is proof. Can you drive a 1 ton truck over a conventional frame home wall without it cracking??





Sing Core Honeycomb Panel description:

  • Strength– Is more than 10 times the strength of aluminum honeycomb core. A one inch by one inch grids aluminum core only has 60 psi; Sing Core 2”x 2” grids have reached more than 660 psi, the smallest core possesses more psi strength, but failed the test against Sing Core. Sing Core grid’s sizes range from 2 in x 1.5 inch to 5 in x 5 inch.
  • Sing Core with Application– Starts from 4 lbs. per cubic ft. and the larger the core grids, the lighter it weighs.
  • Dimensionally Stable– Doors made of Sing Core are guarantee to be true flat. Since we assure the flatness of Sing Core doors, our customers haven’t requested any refunds for their purchase. The most popular door that we manufacture are oversized doors (larger than 7 ft. x 3 ft.). We can do any custom size; the largest door/movable wall we sold was shipped to Bangkok, Thailand and was, 32 ft wide x 16 ft tall (four of them to divide a large conference room to several small conference rooms or a banquet hall).
  • Eco Friendly– Sing Core honeycomb panels are made of renewable veneer. The Sing Core panels take less energy to build a strong composite core, lightweight (which take less energy to transport), has longest life span, and it’s environmentally friendly (compare to other type of core such as paper honeycomb, aluminum honeycomb core, and plastic core).
  • Sing Panels- Come complete with solid wood edging, pvc edge, aluminum edge, or open edges.
  • Skin Choice- Several different skins: such as aluminum, FRP, cement, plastic, and wood. Sing Core products are suitable for indoors/outdoors, plus, our panels are waterproof because of the many different varieties of skin and close cell foam to keep the panels completely watertight. There are two types of wood based panels; paint grade and wood grain.
  • Thickness- Sing Core honeycomb panels come in any thickness from 1/2 in. to more than 8 in. size of Sing panels;The largest door/movable wall we build are 32 ft wide x 16 ft in length (It weighs less than 800 lbs App. 1.5 lb per sq ft),With our patented Sing core biscuit layin under each join  which keep the Sing large oversize panel true dimensionally stable without any movement due the the temperature and moisture change (We offer a 10 year structural guarantee) paint grade.

Multiple Sing Panels can be joined together by a variety of methods to create entire structures or large multi-panel projects on-site using a variety of fastening options.

Galvanized steel equipment enclosures

Sing Core Panels are typically Paint Grade- Produced ready to finish by consumers and businesses. Panels are paint grade, not paint ready, which means that the customer may have to putty, sand and prime before painting.

Custom Choices for Wood Grain- There are paint grades, wood grains skin for Sing panel finish treatment, and there are two type of wood grain Sing panel available. Option 1 is veneer/staves and option 2 is strips/planks. Sing plywood skinned panels are used to build doors, floors, walls, table tops, and roofs; It’s the least expensive and the natural plywood has a thin layer of wood veneer on the surface (the advantages are very affordable, can be stained/ shows beautiful wood, difficult to sand, repair, and has tiny join if it is over 4 ft x 8 ft size).

Two Types of Wood Grain- Sing plank- The 1st type is plywood type of wood skin which uses 1/8 inch wood stave of any kind of wood species, pressed on the top of Sing core panel(advantage: wood stave Sing panel can be sand,repair,like solid wood due to the thicker wood surface).click here to see picture. The 2nd type, is Sing wood grain panel glued to the  natural wood stave slice solid wood to 1/8 inch thick then glue on top of Sing torsion box long panel. Sing true wood planks normally range from 7 in. to 10 in., wide x 8 ft. or 10 ft. in length x 1 1/2 inch thick which look more true flat than real solid wood (click here to see pictures), than glued edges. Sing wood planks can form a large oversize door, table, or wood plank. Sing Core panels could be made at any size and thickness. Sing wood planks are light weight, true flat, fully insulated, and sound deadening than solid wood. Sing Core panels look and function better than solid wood which will warp and shrink. (it would be impossible to join solid wood planks to build doors as large as 10 ft wide x 12 ft or larger). See picture of Sing Core Flooring. Natural planks provide beautiful wood and Sing wood panel invention will make it even more beautiful and function better.



-Instructions For Ordering Panels-

How to order your Sing Core and Sing Core panel :



1.) Download the Order Form Here:

Text format order form download

2.) Review sample and Fill out the form. Email to info@singhome.com

Complete as much as you can, and we’ll take it from there. A non refundable 50% deposit will be required to start your order. We accept all major credit cards, check, cash and wire transfer. You can also print the order form, complete by hand and fax to 360-495-4585.

We offer introductory prices for nonprofits, architects, and interior designers for personal trial use. For all purchases, submit a completed order form to info@singhome.com or by fax: 360.495.4585. Prices vary based on dimensions, skin type and quantity.If you have a tight budget give us a call, we might have an alternative solution tailored to your needs.Because Sing Honeycomb technology is adaptable, we might be able to substitute honeycomb post and beams to achieve the same results.



We make the rice, you make the fried rice! Just choose your dimensions, thickness, and skin. The R&D and design finishing are up to you. You will also find links to designers, architects, and suppliers of: hardware, skin, finishes, windows, and panel fasteners on our links tab.

If you need further assistance contact us via our contact form.

Technical information about Sing core panels

Metals– Aluminum, cold roll steel, galvanize metal, and stainless steel. Thickness ranges from 0.020 in. to 0.125 in. or thicker. Also, there are many choices of color and treatment of those metals to choose from.

Sizes– Seamless 4 ft x 8 ft to 5 ft x 10 ft  (special order 5 ft by 55 ft or longer). With our patented Sing biscuit as the bridge under the joint location, we are able to build panels in almost any size with close precision. The largest door/wall Sing Core has built was, 32 ft. x 16 ft., 2 1/4 in. thick with 2.7 mm thick Luan skin (click here to see picture).

Custom order– We are able to custom build to your individual needs. Sing Core and Sing honeycomb panels are made in the USA with our highly automated facility. We are able to deliver your panel within 24 hours if it is rush job.

Proto Type– OEM and RD, design/product services are available, please contact us for detail. Panel designs are customer driven; we will provide our experience and knowledge to exceed expectations.  Customers are #1 and we look forward to serving you.

Custom Lamination– Our facility has the most advanced equipment to provide large quantities of Sing Cores (truck load per day). We are able to laminate your materials to our Sing Core according to your specifications. Potted inserts, solid wood block implants, helix coils, and tapping of solid aluminum blocks can  be incorporated in Sing Core honeycomb  panels .  These implant and fastener  make it possible to fasten hardware, bolt components (edge enclosure and solid material implant for mechanical fastening). Also, windows and doors are pre-cut to fit the requirements of your design.

Acclimatization:

Sing Honeycomb Panels acclimatizing; according to the type of the skin. Aluminum, metal, plastic skin, concrete, and ceramic skin will be delivered in perfectly straight condition without any acclimatizing, plywood, hardboard, and hpl because it will take much less time to acclimatize than mdf. The best way to acclimatize is stand panels on edge with 4” or more of equal spacing between each panel.



Sing Core Panel

Sing Panels come complete with solid wood edging, or open edged, sandwiched in between the skins. Sing Sandwich Panels and Beams are ready to distribute to consumers and businesses. Sing Sandwich Panels are ready to be stained or painted depending on order type. Just assemble, prepare, paint and enjoy.
